ST-ST Duplex Plastic Fiber Adapter
ST-ST Duplex Plastic Fiber Adapter
Specifications
ST-ST Adapter
1.Good commpatibility
2.Precision-machined
3.High reliability
4.Timely delivery & Small orders accepted
Features
* Type : ST
* Simplex and Duplex
* Single mode and Multimode,APC
* Zirconia sleeves or Phosphor bronze sleeves
* Available without flange or with flange for duplex,saving panel space
* Meet JIS5974 and Bellcore-GR-910-CORE Compliance
* Compliant with IEC874-14 & IEC874-19 and NTT standard compatible
* All parts compliant with RoHS
Application
* Telecommunication
* CATV
* LAN&WAN
* HTTP
| Parameter | ||
| Mode | S.M (Zroz) | M.M (P.B) |
| Insertion Loss | ≤0.2 dB | ≤0.3 dB |
| Mating Durability(500 times) | ≤0.2 dB | |
| Operating Temperature(°C) | -40°C~+75°C | |
| Parameter | ||
| Return Loss | ≥45 dB ( SPC ) , ≥55 dB ( UPC ),≥65 dB ( APC ) | |
| Attenuation Tolerance (dB) | 1-10dB<±1.0dB | |
| 11-25dB<±10% | ||
| 1-10dB<±0.5dB | ||
| 11-25dB<±5% | ||
| Operating Wavelength (nm) | 1310±10nm | |
| 1550±10nm | ||
| 1310 and 1550±10nm | ||
| Operating Temperature(°C) | -40°C+~75°C | |
