Four timer control fiber polisher HK-30F
Product name : Four timer control fiber polisher HK-30F
Products Category: > Fiber Polishing Machine
Four timer control fiber polisher HK-30F
Feature：
4-coil springs pressing structure
Up to 40 connectors polished simultaneously
No quality deviation polishing 1 or 40 connectors at same time
Equipped with the mechanism placing the holder at four corner posts, this machine can precisely
align connectors of uneven heights, ensuring steady polishing at each time.
Built with high quality, heat-treated, stainless steel for amazing precision and durability.
Individual time control: 4 timers on the front panel to set specified time for each steps
Dual speed control: Enable two speeds set for different steps
| Pressure way | 4 coil spring | Insert Loss | 0.3 dB (SM) 0.2 dB (MM) |
| Polishing capacity(max) | SC, FC, ST: 20, 48 units LC: 24, 48units | Return Loss | 50 dB (PC) 60 dB (APC) |
| polishing connector type | FC, SC, ST, LC, MU, MTP, MPO, MTRJ and so on | Radius | 10~25mm |
| Motor speed | 0-140rpm rotation, 2rpm revolution | Offset | 50 μ M |
| Dimension | 310*220*340mm | Under cut | 50nm |
| Film size | 5′ ‘ | Repeatability | 0.1dB |
| Weight | 25KG | Interchangeability | 0.2 dB |
| Input voltage | 100-120VAC, 50/60Hz or 220-240VAC, 50/60Hz | Working Situation Temperature | -10— +40º C |
| Polishing cycle | 2.83mins | Heavy punch | 500g or 250g |
| Polishing chassis diameter | 130mm | ||
| Polishing time setting | 0-3min | ||
| Counterweight pressure | 2.1~3.6kgf/cm | ||
| Time Range | 0-300S | ||
| Polishing Time | 2 min. (quick assembly type) | ||
| 3-4 min. (standard connectors) | |||
| Pressure Range | 0~5kg | ||
| Precession Speed | 2rpm |
