Hot Stripper TS Plus Koera INNO

Hot Stripper TS Plus Koera INNO

Plus specializes in heating and stripping ribbon cables. With its simple and quick operation, anyone can peel off perfectly. Using lightweight materials and a compact design, it is a very stable tool. Easy to operate with one hand, with long-lasting battery life: stripping ribbon fiber about 500 times.

characteristic

Durable ribbon fiber stripper Specially designed for strip fiber stripping Handheld hot stripper World’s fastest heating time: 4 seconds Long battery life: stripping ribbon fiber about 500 times

Size and weight

Height: 1.33 ft (34 mm)
Width: 5.47 ft (139 mm)
Length: 1.33 ft (34 mm)
Width: 0.66 with battery (302 lbs)
0.57 without battery (260 lbs)

Way of use

1. Turn on the TS-8 and select the appropriate temperature and mode.

2. Place the fiber clamp to ensure that the fiber part needs to be stripped from the hot stripper body and the cover is closed.

3. Press and hold the cover until the temperature indicator flashes.

4. Push the clamp part out of the heat stripper body, open the clamp cover, and check the fiber stripping status.

Fiber material
Quartz glass
Coating material
UV curing resin
Coating thickness
Single core: 0.25~0.4mm 2-12 core strip: 0.3~0.4mm
Cladding diameter
125μm
Coating peel length
30mm maximum
Heating mode
Normal mode / power saving mode
Temperature setting
Normal mode: approx. 80°C, 95°C, 110°C, 130°C
Power saving mode: approx. 70°C, 80°C, 95°C, 110°C
Fiber clamp type
FH-2, FH-4, FH-6, FH-8, FH-10, FH-12, FH-250, FH-900,
FH-U (using 250μm or 900μm fixture)
Power supply
1) AC power: AC100~240V, 50/60Hz
2) DIN interface: DC 12V welding machine power supply
Operating condition
Temperature: 0°C~40°C / Humidity: 0%~95%
Applicable fiber type
Single core: 250μm, 900μm, 3.0mm fiber and leather cable ribbon fiber: 2-12 core ribbon fiber
heating time
Normal mode: 4~5 seconds
Power saving mode: 5~6 seconds
battery capacity
Stripping 12-core ribbon fiber 500 times on a single charge
