Shenzhen Homk Telecom Tech Co., Ltd.
ODC outdoor fiber optic patch cord assembly protected branch cable…
Product name : ODC outdoor fiber optic patch cord assembly protected branch cable…
Products Category: > Waterproof Fiber Series Products
ODC outdoor fiber optic patch cord assembly protected branch cable for 3G/4G base station
Price-Competitive
Low Insertion Loss & PDL
Factory-terminated and Tested
Features
• Robust fiber-optic connector for 2 and 4 channels with screwed mating mechanism
• IP68 protection, salt-mist proof, and EMI protection
• High shock, vibration, and mechanical resistance
• Broad temperature range and wide range of indoor and outdoor cables
• Easy, reliable and cost-effective installation
Specifications
1.ODC-2, ODC-4 channels can select
2. PVC, LSZH cables are available
3.Waterproof, dust proof and corrosion resistan
HOMK-Fiber fiber optic products for harsh environment are designed to withstand severe mechanical loads, high thermal exposure, and demanding environments like rain, salt and splash water.
ODC harsh environment cable assemblies are installation-friendly for fixed or mobile applications and transmit reliably data over long distances under severe environmental conditions.
Pecification
| Fiber Core | 2,4,6,8 etc | |||
| Mode | Singlemode | Multimode | ||
| Operating Wavelength(nm) | 1310/1550 | 850/1310 | ||
| Polishment | UPC | APC | UPC | |
| Insertion Loss(Max.dB) | 0.7 | 0.6 | ||
| Return Loss(Min.dB) | 55 | 60 | 35 | |
| Mating times | 500 Min | |||
| Durability(Max.dB) | 0.2 | |||
| Reaptability(Max.dB) | 0.5 | |||
| Operating Temperature(℃) | -40~+85 | |||
| Storage Temperature(℃) | -40~+85 | |||
