Shenzhen Homk Telecom Tech Co., Ltd.
48core Rack Mount Patch Panel/ODF enclosure/Terminal box
Product name : 48core Rack Mount Patch Panel/ODF enclosure/Terminal box
Products Category: > Fiber Splice Closure & ODF & Terminal box
48core Rack Mount Patch Panel/ODF enclosure/Terminal box
Applicable in the termination and 19” standard structure,sliding design,rack mounted Suitable for FC,SC,ST,LC adapters
Features:
1. Applicable in the branch connection of fiber termination, working as distribution box
2.19” or 21” standard structure, rack mounted
3. Available for the installation of FC, SCadaptors
4. Size: can meet with customer’s requires
5. The body is made of cold rolled steel sheet, with electrostatic spraying. We can install adaptors for you, available for FC, SC
Application:
FTTH
Telecommunication networks
CATV Networks; LAN Network
Active device termination
Order information
| Tyep | Dimension(mm) | Max capacity(cores) | Remark |
| SPRM1-SC12 | 430*300*1U | 12 | Cold rolled steel sheet,with electrostatic spraying,
suitable for FC,SC,ST,LC adapters. |
| SPRM1-FC24 | 24 | ||
| SPRM1-2SC24 | 48 | ||
| SPRM1-FC48 | 430*300*2U | 48 |
Packing information
| Type | Inner carton size
(mm) |
Weight
(kg) |
Packing size
(mm) |
Weight
(kg) |
No./ carton |
| SPRM1-SC12 | 465*330*75 | 5.5 kg | 485*420*350 | 29.0 kg | 5 |
| SPRM1-FC24 | |||||
| SPRM1-2SC24 | |||||
| SPRM1-FC24 | 475*335*130 | 6.2kg | 500*355*550 | 26.3kg | 4 |
